Value Series Face Access Terminal

Face mask wearing alert: If the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, the authentication or attendance is valid

Forced mask wearing alert: If the recognizing face does not wear a mask, the device will prompt a voice reminder. At the same time, the authentication or attendance will be failed

Max.3000 faces capacity, Max.3000 fingerprints capacity, and Max.3000 cards

Face Recognition Terminal, 4.3-inch LCD touch screen,2 Mega pixel wide-angle lens,Built-in Mifare card reading module

Two-way audio with client software, indoor station, and main station

Supports TCP/IP

Supports ISUP5.0, ISAPI

Configuration via the web client

Face Recognition Distance: 0.3 m to 1.5 m

Duration ＜ 0.2 s/User

Accuracy rate ≥ 99%; IP65

• Display
• Dimensions4.3-inch
• TypeLCD
• Operation MethodCapacitive touch screen

• Video
• FOVHFOV = 41.5°; VFOV = 75.5°; DFOV = 87°
• Pixel2 MP (video stream: 720P)
• Lens× 2

• Audio
• Tone QualityNoise suppression and echo cancellation

• Network
• Wired Network10 M/100 M/1000 M self-adaptive

• Interface
• Network Interface1
• RS-4851
• Wiegand1
• Lock Output1
• Exit Button1
• Door Contact Input1
• Power Interface2-pin

• Capacity
• Card Capacity3,000
• Face Capacity3,000
• Fingerprint Capacity3,000
• Event Capacity150,000

• Authentication
• Card TypeM1 card
• Card Reading Frequency13.56MHz
• Face Recognition Duration＜ 0.2 s
• Face Recognition Accuracy Rate＞99%
• Face Recognition Distance0.3 to 1.5 m
• Fingerprint Recognition Duration＜1s

• Function
• QR Code RecognitionSupport
• Face Anti-SpoofingSupport
• Audio PromptSupport
• Time SynchronizationSupport

• General
• ButtonTouch Screen
• Power Supply Method2 pin connecter
• Power Supply12 VDC, 2 A. (power adapter not included)
• Working Temperature-30 °C to 60 °C (-22 °F to 140 °F)
• Working Humidity0 to 90% (No condensing)
• Dimensions172.5 mm × 83.2 mm × 22.7 mm (6.79" × 3.27" × 0.89")
• Protective LevelIP65
• InstallationSurface mounting
• LanguageEnglish, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil)
• PlatformHik-ProConnect and HikCentral Professional
